Mmo Flexible Anode Sacrificial Anodes With Diameter 1.0mm Wire With Ir Ta Coating Sock Stuff

Large Image : Mmo Flexible Anode Sacrificial Anodes With Diameter 1.0mm Wire With Ir Ta Coating Sock Stuff

Product Details:

Place of Origin:	CHINA
Brand Name:	High Broad or OEM
Certification:	ISO
Model Number:	ASTM B348 GRADE I/II

Payment & Shipping Terms:

Minimum Order Quantity:	600 meters
Price:	discussed
Packaging Details:	in roll
Delivery Time:	10000 meters : 10 days
Payment Terms:	T.T , L.C, D/P
Supply Ability:	50000 meters per month

Contact Now

Detailed Product Description

Application:	Large Current And Small Grounding Resistance	Standard:	ASTM B348 GRADE I/II / Coke Stuff
Shape:	Mixed Metal Oxide Titanium Flexible Anode	MMO:	Impressed Current C Anode

MMO/Ti flexible anode

Linear anode also called flexible anode , it can be classified into two categories: linear anode based on the nano conductive Linear anode also called flexible anode , it can be classified into two categories: linear anode based on the nano conductive carbon black polymer composite technology and linear anode based on MMO/Ti coating. The former is the first generation and the latter are the second generation. Both of them are used for impressed current cathodic protection of buried structures, such as buried oil (gas) pipelines, underground tank, petrochemical container etc. in order to slow down corrosion. The linear anode is characterized by easy installation, completed supporting facilities and reasonable price.


Diameter of flexible anode	39+/-2 mm
Average Thickness of conductive polymer	>= 4 mm
Volume Resistivity of conductive polymer	1.5 Ω˙cm
Take a 0.2meter sample and put it into 3% NACI solution with a constant current of 40mA for one month	The consumption of carbon black is of the visible inlet ring radius
Output current	52 mA/m
Designed service life of anode	>= 25 years
Carbon content of packing coke powder	>= 98%
Resistivity of coke powder	<= 0.55 Ω˙cm
Fabric Cladding Jacket of anode	Resistant to acid/alkaline and chlorine; Permeable
External woven mesh	Resistant to Abrasion and ambient temperature variation
Weight of anode	>= 1.3 kgs/meter
Length of each coil	700 meters or customized

Mmo Flexible Anode Sacrificial Anodes With Diameter 1.0mm Wire With Ir Ta Coating Sock Stuff

For the existing tank, MMO/Ti linear anodes and grid anodes cannot be used, impressed-current anodes should be usually anode and traditional distribute anode.

Technical Feature of Anode:

1, Covers an area of less

2, Protective current distribution equality

3, Relatively little interference

4, Central portion of the Outer surface of tank can be effectively protected.

5, Convenient installation

6, Low cost
