Name: | Magnesium Ribbon Anode AZ63/MgMn | Material: | High Potential Mg Alloy Sacrificial Anode For Cathodic Protection |
---|---|---|---|
ISO9001:2008: | The Ribbon Mg Alloy Sacrificial Anode | Usage: | Mg Ribbon Anode For Anti-corrosion/Cathodic Protection |
Dimensions: | AZ91 Magnesium Alloy Sacrifice Anode Ribbon | Standard: | ASTM Magnesium Ribbon Anode For Underground Pipeline |
Shape: | Extruded Magnesium Ribbon Anodes For HP & AZ Type | Other Name: | ANTI-CORROSION Mg Anode Al Anode Zn Anode |
ASTM Magnesium Anode: | Extruded Rod & Ribbon Magnesium Anodes | Extruded Mg Anode: | 9.5*19mm Magnesium Ribbon Anode Mg Anode For CP |
Galvanic Anode Manufacture: | Galvanic Anode For Cathodic Protection | ||
Highlight: | aluminum sacrificial anodes,aluminum anodized |
Standard : ASTM G-97
Chemical composition of magnesium ribbon anode, %
Mn | Zn | Al | Cu | Ni | Fe | Si | Impurities | Mg | |
Each | Total |
| |||||||
0.50-1.3 | ---- | 0.01 | 0.02 | 0.001 | 0.03 | --- | 0.05 | 0.30 | Bal. |
0.20 min | 0.7-1.3 | 2.5-3.5 | 0.01 | 0.001 | 0.002 | 0.05 | 0.05 | 0.30 | Bal. |
Specification of magnesium ribbon anode
Section (inch) | 3/8X3/4± 0.015 (1/8" corner) |
Diameter of core (inch) | 0.135 |
Core eccentric (inch) | <1/16 |
Weight (lbs/feet) | 0.243 |
Standard coil length (feet) | 1000 |
Coil weight (lbs) | 243 (110kg) |
For high resistivity environment, the protection of the casing pipe, pipeline cathodic protection temporarily, tank and pipe network protection against strong electrical interference grounding grid.
We are a professional anode supplier over 16 years ,mainly supply:
* Zinc anodes (ASTM B418-95 US MILL 18001K)
* Al-Zn-In anodes (GAIII)
* Magnesium anodes ( ASTM-G97)
* High silicon cast iron anodes ( ASTM-A518-3,BS1591)
Our anodes are shipped worldwide especial main to North America, Asia etc., around 5000mt per year. Our goods are regularly tested by independent third party lab in USA to keep anode continuous high quality. Our plant owns raw material resources ore, so we can supply very good price with service for you.
We can also accept customized anodes with your logo according to your drawing !
Our Belief: Continuous Innovation.
Our Spirit: Sincerity, Unity, Dedicated, Hardworking.
Our Mission: Provide most advanced products & most professional technical solution.
