Magnesium Alloy Metal Sheet Plate

Large Image : Magnesium Alloy Metal Sheet Plate

Product Details:

Place of Origin:	China
Brand Name:	High Broad or OEM
Certification:	ISO
Model Number:	AZ31B,AZ91D,ZK60,WE43

Payment & Shipping Terms:

Minimum Order Quantity:	10 kgs
Price:	negotiable
Packaging Details:	In carton, on pallet
Delivery Time:	100 kgs: 7 days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
Supply Ability:	100mt/month

Contact Now

Detailed Product Description

Product Name:	Magnesium Alloy Plate For CNC Engraving,Embossing,Etching,Stamping	Other Name:	Magnesium Alloy Sheet
Material:	Magnesium Alloy	Application:	CNC Engraving,Embossing,Etching,Stamping
Type:	Hot Roll, Extruded,Cast	Surface:	Without Coating
Industrial:	Computer,Printing,Camera,Cellphone
Highlight:	metal sheet plate , magnesium engraving plate

Magnesium Alloy Plate for CNC engraving Embossing Etching Stamping

Specifications:

Commodity : Magnesium alloy plate/Magnesium alloy Sheet

Type : AZ31B ,AZ91D,ZK60,WE43 etc

Sheet Size Range:
Thickness from 0.5mm to 300mm;
Width is 1000mm max.;
Length is 1800mm max.;

Chemical Composition:

Al: 2.5-3.5%; Zn: 0.7-1.3%; Mn: 0.20 – 1.0%; Mg: Balance

PHYSICAL PROPERTIES:

Density: 1.78

Coefficient of thermal expansion: 26.8 x 10^-6K^-1

Specific heat: 1040 Jkg^-1k^-1

Thermal conductivity: 76.9Wm^-1k^-1

Electrical resistivity: 92nΩm

Modulus of elasticity: 45 x 10⁹Pa

Poissons ratio: 0.35

Melting range: 566 - 632°C

Applications:

Sheet and plate in AZ31B find application in medium strength service at temperatures below 150°C. Diverse uses including aerospace, aircraft, concrete tools, 3C (cell phone / camera / computer), speaker cones and textile machinery can all benefit from light weight AZ31B.

AZ31B is non-magnetic and has high electrical and thermal conductivity filling the requirements for RFI and EMI shielding in the electronics and computer industries.

Superplastic forming of AZ31B sheet at elevated temperatures allows production of a wide variety of intricate parts for automotive uses. Monocoque construction utilizing formed sheet can be adapted to many commercial applications.

Magnesium Alloy Metal Sheet Plate

Our Sales office & workshop & lab:

Magnesium Alloy Metal Sheet Plate

Contact me for more details:

Vivian Jiang

International Marketing Manager

Email: metal@vip.163.com

Tel: +86-731-85717705

Fax: +86-731-85716569

Mobile/whatsapp: +86-139-7488-3816

Skype: vivian.jjy
