WE43 T5 AZ31B H24 Magnesium Engraving metal alloy Plate sheets For Lable / PVC / Shoes Mould

Good quality Aluminum Sacrificial Anode for sales
Good products, Nice services. I trust High Broad brand.

—— Sheikh Abdulla

I puchase cathodic protection anodes from High Broad from year 2006. We worked well as best partners.

—— Narrisa Kotsonis

I'm Online Chat Now

WE43 T5 AZ31B H24 Magnesium Engraving metal alloy Plate sheets For Lable / PVC / Shoes Mould

China WE43 T5 AZ31B H24 Magnesium Engraving metal alloy Plate sheets For Lable / PVC / Shoes Mould supplier
WE43 T5 AZ31B H24 Magnesium Engraving metal alloy Plate sheets For Lable / PVC / Shoes Mould supplier WE43 T5 AZ31B H24 Magnesium Engraving metal alloy Plate sheets For Lable / PVC / Shoes Mould supplier WE43 T5 AZ31B H24 Magnesium Engraving metal alloy Plate sheets For Lable / PVC / Shoes Mould supplier WE43 T5 AZ31B H24 Magnesium Engraving metal alloy Plate sheets For Lable / PVC / Shoes Mould supplier

Large Image :  WE43 T5 AZ31B H24 Magnesium Engraving metal alloy Plate sheets For Lable / PVC / Shoes Mould

Product Details:

Place of Origin: China
Brand Name: High Broad or OEM
Certification: ISO
Model Number: WE43 WE54 WE75 WE94

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece if we have stoc, 100 kgs if no stock
Price: negotiable
Packaging Details: In carton, on pallet
Delivery Time: 100 kgs: 7 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
Supply Ability: 100mt/month
Detailed Product Description
Product Name: Lable Mould PVC Mold Shoes Mould Other Name: Magnesium Alloy Sheet
Material: Mg Plate Application: CNC Engraving,Embossing,Etching,Stamping
Type: Hot Roll, Extruded,Cast , Cast & Roll Surface: Polished
Industrial: Computer,Printing,Camera,Cellphone
Highlight:

metal sheet plate

,

magnesium engraving plate

WE43 T5 AZ31B H24 Magnesium engraving plate for lable / PVC / Shoes mould



WE43 T5 AZ31B H24 Magnesium engraving plate for lable / PVC / Shoes mould

Magnesium plates Specifications

Magnesium plates Sheet: Thickness: 1 - 6mm; Max. width: 600mm;
Magnesium plates Plate: Thickness: 10 - 200mm; Max. width: 2500mm;
Max. length: 6000mm
AZ31B



Magnesium plates Sheet: Thickness: 1 - 6mm; Max. width: 600mm;
Magnesium plates Plate: Thickness: 10 - 200mm; Max. width: 2500mm;
Max. length: 6000mm

Magnesium plates AZ31B Sheet, Plate, Block and coil



Magnesium plates AZ31B is a wrought magnesium base alloy with good room-temperature strength and ductility combined with corrosion resistance and weldability. Increased strength is obtained by strain hardening with a subsequent partial anneal (H24 and H26 tempers).



Magnesium plates SIZE RANGE:

Sheet: thickness from 1mm to 6mm; Max. width is 600mm; Max. length is 6000mm;

Plate: thickness from 6 mm to 200mm; Max. width is 2500mm; Max. length is 6000mm;

Block: We can supply cut-to-size blocks according to customer's requirements.

Coil: thickness from 0.5 to 2.7mm, max. width 240mm;



Magnesium plates APPLICATIONS

Magnesium Sheet and plate in AZ31B find application in medium strength service at temperatures below 150°C. Diverse uses including aerospace, aircraft, concrete tools, 3C (cell phone / camera / computer), speaker cones and textile machinery can all benefit from light weight AZ31B.

Magnesium plates AZ31B is non-magnetic and has high electrical and thermal conductivity filling the requirements for RFI and EMI shielding in the electronics and computer industries.

Superplastic forming of AZ31B sheet at elevated temperatures allows production of a wide variety of intricate parts for automotive uses. Monocoque construction utilizing formed sheet can be adapted to many commercial applications.



Magnesium plates SPECIFICATIONS

ASTM B90/B90M-07; AMS 4375; AMS 4376; AMS 4377



Our Sales office & workshop & lab:

WE43 T5 AZ31B H24 Magnesium Engraving metal alloy Plate sheets For Lable / PVC / Shoes Mould



WE43 T5 AZ31B H24 Magnesium Engraving metal alloy Plate sheets For Lable / PVC / Shoes Mould





WE43 T5 AZ31B H24 Magnesium Engraving metal alloy Plate sheets For Lable / PVC / Shoes Mould







The characteristics of magnesium alloy plate: its processing and corrosion and mechanical properties have many characteristics: fast heat dissipation, light weight, good rigidity, certain corrosion resistance and dimensional stability, impact resistance, wear resistance, good attenuation performance and easy recycling ; In addition, there are high thermal and electrical conductivity, non-magnetic, good shielding and non-toxic characteristics.





Type Mg Al Si Ca Zn Mn Fe Cu Ni
AZ31B Balance 2.5-3.5 0.08 0.04 0.6-1.4 0.2-1.0 0.003 0.01 0.001
