Thick: | 0.1 Mm 0.2 Mm 0.5mm 1.0 Mm | Grade: | AZ31 Pure Mag 99.9% |
---|---|---|---|
Highlight: | metal sheet plate,magnesium engraving plate |
ISO / Rohs Magnesium Foil Thickness 0.25 Mm Size 100 × 100 Mm Purity 99.9%
Magnesium foil thickness 0.25 mm size 100 × 100 mm purity 99.9%
Grade: AZ31 , Pure Mg etc.
First, the rolling magnesium alloy sheet size and performance
3.1 Dimension deviation
Plate thickness deviation: ± 8%;
Width deviation: ± 3mm;
Length deviation: ± 5mm.
3.2 Mechanical properties
3.2.1 Rolled state: AZ31:
Yield strength> 180MPa;
Tensile strength> 200MPa
Elongation> 7%
3.2.2 annealed state: AZ31:
Yield strength> 140MPa;
Tensile strength> 160MPa
Elongation> 12%
3.2.1 Rolled state: AZ91:
Yield strength> 200MPa;
Tensile strength> 300MPa
Elongation> 3%
3.2.2 annealed state: AZ91:
Yield strength> 150MPa;
Tensile strength> 250MPa
Elongation> 12%
