Product Details:
Payment & Shipping Terms:
|
| Grade: | ZK61A M1A MB6 MB3 MB1 MA8 MA1 MA14 MA5 MA2 | Engrave: | Magnesium Alloy Sheet AM60B For Engraving Stamping |
|---|---|---|---|
| Application: | Luggage Nameplate, Bags | Dimensions: | Customized |
| Highlight: | metal sheet plate,magnesium engraving plate |
||
ASMTB90 Mg Alloy Az31b Magnesium Plate Sheet 5mm X 250 Mm X 500mm Size
Magnesium Alloy Sheet AM60B for Etching Engraving Stamping
laser engraving sheet/magnesium alloy sheet az91d/magnesiumprinting plate
Elements | AZ31B | AZ61A | AZ91D | |||
Min % | Max % | Min % | Max % | Min % | Max % | |
Al | 2.50 | 3.50 | 5.80 | 7.20 | 8.50 | 9.50 |
Zn | 0.60 | 1.40 | 0.45 | 1.50 | 0.45 | 0.90 |
Mn | 0.20 | 1.00 | 0.15 | 0.50 | 0.17 | 0.50 |
Si | - | 0.10 | - | 0.10 | - | 0.08 |
Fe | - | 0.005 | - | 0.005 | - | 0.004 |
Cu | - | 0.05 | - | 0.05 | - | 0.025 |
Ni | - | 0.005 | - | 0.005 | - | 0.001 |
Ca | - | 0.04 | - | - | - | - |
Others, Total | - | 0.3 | - | 0.3 | - | 0.3 |
Mg | Balance | Balance | Balance | Balance | Balance | Balance |
Product specifications: Extruded sheet: thickness 5mm—105mm, width 10mm—400mm, can be customized for special needs
Rolled plates: thickness 0.3mm-5mm, width 10mm-500mm, special requirements can be customized. Product application: Magnesium alloy plate is widely used in aerospace, electronics, 3C, chemical and other industries.
Because magnesium alloy has good thermal conductivity and low cutting force, the heat dissipation rate during processing is very fast, so the tool life is long and the amount of sticking is small.
As a result, tool costs can be reduced, and the downtime required for tool replacement can be shortened. Because magnesium is easy to cut, its chip breaking performance is very good, under normal circumstances, only one finishing process can achieve the required final surface finish.
Magnesium alloy strips are produced by hot rolling ingots and coils, which are flexible in production and can produce ultra-wide and large-size magnesium strips to meet the needs of various industries. Magnesium alloy machined plates are used as vibration parts, and their service life is 5 times that of aluminum parts.
Magnesium alloy plates-grades AZ31, AZ91, MB8, ZK61M. The thickness is: 0.5mm-200mm.
