Doule Venturi single Entrance Sand Blast Gun Boron Carbide Spray Nozzle for Cleaning Equipment

Large Image : Doule Venturi single Entrance Sand Blast Gun Boron Carbide Spray Nozzle for Cleaning Equipment

Product Details:

Place of Origin:	China
Brand Name:	OEM/High Broad
Certification:	ISO, DNV,BV
Model Number:	Hotpress B4C Nozzle ceramic sandblast nozzle

Payment & Shipping Terms:

Minimum Order Quantity:	10 pieces
Price:	negotiable
Packaging Details:	Each nozzle packed in a plastic tube, then in a carton
Delivery Time:	500 pieces:15 Days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram,PayPal
Supply Ability:	1000 pieces per month

Contact Now

Detailed Product Description

Name:	Sandblasting Boron Carbide Spray Nozzle For Cleaning Equipment	Keyword:	Hotpress Ceramic Sandblast Nozzle
Advantage:	High Temperature Resistance, Abrasion-resistance, Light Unit Weight, Working Life Much Longer Than Tradition Material	Shape:	Straight Core,Ventui Type Boron Carbide Ceramic Sandblast Nozzle
Type:	Doule Venturi,single Entrance	Usage:	Sandblasting Machines, Hydraulic Cutters, Power Plant Boilers
Rubber Jacket:	Coarse Thread Long Venturi Boron Carbide Rubber Jacket Sand Blast Nozzles	OEM:	Manufacturing Blast Nozzle Boron Carbide Nozzle
Highlight:	Sandblasting Gun , Sand Blasting Gun

Doule Venturi single Entrance Sand Blast Gun Boron Carbide Spray Nozzle for Cleaning Equipment

Sand Blasting Nozzle

High temperature resistance, Abrasion-resistance, light unit weight, working life much longer than tradition material.

Specifications:

Density: 2.40-2.65 g/cm3

Elastic modulus: 510 Gpa

Knoop Hardness: 3300

Flexural strength: 400-650 Mpa

Compressive strength: 4100 Mpa

Fracture toughness: 4.5-7.0 Mpa.m1/2

Coefficient of thermal expansion: 4.5x106

Thermal Conductivity: 29 m0k

Maximum permissible service temperature in air: 1500℃

Regular size list for straight core

Diameter(mm)	Diameter (mm)	Length(mm)
20	4	45
20	6	45
20	8	45
20	10	45

Diameter(mm)	Diameter (mm)	Length(mm)
20	6	60
20	8	60
20	10	60

Diameter(mm)	Diameter (mm)	Length(mm)
20	6	80
20	8	80
20	10	80

Diameter(mm)	Diameter (mm)	Length(mm)
21	8	82
21	10	82
21	12	82

Other sizes:

Diameter(mm)	Diameter (mm)	Length(mm)
15	6	55
15	8	55
25	8	60
25	10	60
25	12	60
30	8	40
30	10	40
30	12	40
30	14	40

Venturi type:

Coarse thread and Fine thread

Boron carbide nozzle insert with Aluminum or stainless steel jacket

Entrance width	Entrance depth	Bore	Exit	Length
32	40	6.5	10.5	135
32	45	8.0	12.0	150
32	48	95.	14.0	165
32	52	11.0	15.5	190
32	58	12.5	17.0	215
Entrance width	Entrance depth	Bore	Exit	Length
25	28	6.5	10.5	135
25	35	8.0	12.0	150
25	38	95.	14.0	165
25	42	11.0	15.5	190
25	42	12.5	17.0	215

(mm)

Material Comparation Chart:

Item	Al2O3	SiC	B4C
Density	3.5g/cm3	3.1g/cm3	2.4-2.65g/cm3
Hardness	HV1650	HV2750	HV3300
Flexural strength	290 Mpa	380 Mpa	400-650 Mpa
Compressive strength	850 Mpa	3970 Mpa	4100 Mpa
Fracture toughness	4.8 Mpa.m1/2	4.0 Mpa.m1/2	4.5-7.0 Mpa.m1/2
Thermal Conductivity	20 m0k	120m0k	29 m0k
