Product Details:
Payment & Shipping Terms:
|
| Material: | Water Heater Anode | Certificate: | ISO9001:2008 Zinc Anode Rod For Cooler System |
|---|---|---|---|
| Related Products: | Complete Zinc Pencil Anode With Brass Plug 1/4" NPT X 3" Engine Zinc | Detail: | M6*20*200 20cm Shank Length M6 5.7mm Male Dia 20mm Shank Diameter Magnesium Anode Rod For Waterboiler |
| Cleaning: | Magnesium Alloy Sacrificial Anode Formed One Power Plant And E Lectromagnetic Vibration By Current In The Container Or Piping | Application: | It's For Compact Non-pressurized Solar Water Heater! |
| Highlight: | water heater rod anode,water heater anode rod replacement |
||
M6*20*200 20cm Shank Length M6 5.7mm Male Dia 20mm Shank Diameter Magnesium Anode Rod for Waterboiler
Water heater anode rod or sacrificial anode is the important component part with only one purpose to protect metal tank from corrosion.Extruded Alumnium anodes and Magnesium anodes have high current to weight ratio,are suitable to be used in where a small diameter anode is required to give enough cathodic current.
HB supply extruded anodes in both high potential (Mg-Mn alloy),standard potential (AZ31 alloy) and Alumnium Alloy.Our extruded anodes are typically suitable for all kinds of water storage tanks or in prepolarization of offshore structure and so on.
Specification
| Alloy | AZ31B | Mg-Mn | Aluminum | |
| Chemical Composition | Aluminum | 2.50-3.50% | 0.01% Max | Balance |
| Manganese | 0.20-1.00% | 0.50-1.30% | - - | |
| Zinc | 0.60-1.40% | - - | 4.00-5.00% Max | |
| Calcium | 0.04% Max | - - | - - | |
| Silicon | 0.10% Max | - - | 0.25% Max | |
| Copper | 0.01% Max | 0.02% Max | - - | |
| Nickel | 0.001% Max | 0.001% Max | - - | |
| Fe | 0.005% Max | 0.03% Max | 0.25% Max | |
| Sn | -- | - - | 0.05-0.25% Max | |
| Other purity(each) | -- | 0.05% max | - - | |
| Total purity | 0.30% Max | 0.30% Max | 0.15% Max | |
| Remaining | Magnesium | Magnesium |
| Diameter(inch) | Core eccentric(inch) | Core diameter(inch) | Straightness(inch/2 ft length) | Weight(lbs/inch) |
| Magnesium Extruded rod | ||||
| 0.0675-0.020 | 0.050 | 0.135 | 0.060 | 0.025 |
| 0.750-0.020 | 1/16 | 0.135 | 0.040 | 0.031 |
| 0.800-0.020 | 1/16 | 0.135 | 0.040 | 0.035 |
| 0.840-0.020 | 1/16 | 0.135 | 0.040 | 0.038 |
| 0.900-0.020 | 1/16 | 0.135 | 0.040 | 0.043 |
| 1.050-0.020 | 1/16 | 0.135 | 0.040 | 0.057 |
| 1.315-0.020 | 1/16 | 0.135 | 0.040 | 0.089 |
| Aluminum Extruded rod | ||||
| 0.576-0.020 | 0.050 | 0.135 | 0.060 | 0.038 |
| 0.750-0.020 | 1/16 | 0.135 | 0.050 | 0.048 |
Thread Size: DN20
Length: 23CM(Exclude the copper fitting)
Mainly used in water boiler, heat exchanger, evaporimeter, and boiler and so on. It has properties of softing water, de-dirt residual ,en-longing the working life of container
| Product Name | Extruded Magnesium Anode Rod |
| Material | Magensium |
| Fit for | Waterboiler, Heatexchanger, Vapourater, Boiler |
| Male Diameter | 5.7mm/ 0.22" |
| Male Part Length | 3cm/ 1.18 |
| Shank Diameter | 13mm/0.51 " |
| Shank Length | 13.5cm/5.3 " |
| Total Length | 16.5cm/ 6.5" |
| Color | Silver Tone |
13.5cm Shank Length M6 5.7mm Male Dia Magnesium Anode Rod for Waterboiler
Advantages:
(1)Corrosion protection,
(2)protect water heater, water containers of steel structure,
(3)protect the gas pipeline in-home service polarization high resistance electrolytes (soil and water in the steel structure)
China High Broad New Material Co.,ltd was established in 2006 and we are specialized in manufacturingMagnesium/AluminumExtrusion/casting products. The range of our product line, excellent quality & service, low price over the past ten years have made us one of the leading companies of its kind in China.
It’s our principal aim to provide the highest quality of materials and integrity of services, so our customer can focus all of their efforts in the more profitable services such as design, Marketing.
Taking advantage of the advanced technology and low labor cost, high broad is always able to provide high quality products and integrity customer services backed with the most competitive price.
Please select us as your honest and reliable partner to save your money and time.
Factory occupation 55000 square meter
Total staff 220
Management & Technical staff 50
Capacity:
