MMO / Ti Flexible Anodes Mixed Metal Oxide Titanium Flexible Anode / Conductive Polymer Linear Anode

China MMO / Ti Flexible Anodes Mixed Metal Oxide Titanium Flexible Anode / Conductive Polymer Linear Anode supplier
MMO / Ti Flexible Anodes Mixed Metal Oxide Titanium Flexible Anode / Conductive Polymer Linear Anode supplier MMO / Ti Flexible Anodes Mixed Metal Oxide Titanium Flexible Anode / Conductive Polymer Linear Anode supplier MMO / Ti Flexible Anodes Mixed Metal Oxide Titanium Flexible Anode / Conductive Polymer Linear Anode supplier

Large Image :  MMO / Ti Flexible Anodes Mixed Metal Oxide Titanium Flexible Anode / Conductive Polymer Linear Anode

Product Details:

Place of Origin: CHINA
Brand Name: High Broad or OEM
Certification: ISO
Model Number: ASTM B348 GRADE I/II

Payment & Shipping Terms:

Minimum Order Quantity: 600 meters
Price: discussed
Packaging Details: in roll
Delivery Time: 10000 meters : 10 days
Payment Terms: T.T , L.C, D/P
Supply Ability: 50000 meters per month
Detailed Product Description
Application: Large Current And Small Grounding Resistance Standard: ASTM B348 GRADE I/II
Shape: Mixed Metal Oxide Titanium Flexible Anode MMO: Impressed Current C Anode

Continuous Linear anodes,Impressed Current Cathodic protection MMO/Ti Linear anodes



Mixed Metal Oxide (MMO) and linear anode systems for storage tank soil side corrosion prevention, have long been established as the go-to anode system for corrosion prevention systems. However, the effectiveness of these anodes



  •
  •
Diameter of flexible anode 39+/-2 mm
Diameter of MMO/Ti anode wire >= 1.0 mm
Designed service life of anode >= 25 years
Consumption rate of MMO/Ti anode wire ( with backfill materials) <= 6 mg/A.a
Output current
  1.
Thickness of metallic oxide coating >= 6 g/m2
Resistivity of mixed metallic oxides(Ω/cm) 10 -5Ω˙cm
Contact Resistance at the joints between andoe and cable <= 1mΩ
Resistance of anode <= 0.007 Ω/m
Carbon content of backfill coke powder >= 98%
Resistivity of coke powder <= 0.55 Ω˙cm
Fabric cladding jacket of anode Resistant to acid/alkaline and chlorine; Permeable
External woven mesh Resistant to abrasion and ambient temperature variation
Weight of anode >= 1.3 kgs/meter
Length of each coil 700 meters or customized





MMO / Ti Flexible Anodes Mixed Metal Oxide Titanium Flexible Anode / Conductive Polymer Linear Anode



MMO / Ti Flexible Anodes Mixed Metal Oxide Titanium Flexible Anode / Conductive Polymer Linear Anode



Applications for cathodic protection include:

  • Aboveground storage tanks
  • Underground metallic storage tanks
  • Water storage tanks, both soil side and water-contact surfaces
  • Underground metallic pipelines
  • Power plant structures: intake, discharge, circulating water, fuel systems
  • Marine structures
  • NACE (National Association of Corrosions Engineers) Compliant Testing
  • Field Gas Distribution System Inspections
  • Master Meter System Federal Compliance Reviews
  • Master Meter System State Compliance Reviews
  • Construction Gas Distribution System Inspections
  • Pipeline Integrity Inspections
  • Pipeline Location/Survey Inspections
  • Gas Distribution System Welding Inspectors
  • Civil Inspections
  • Utility Inspections
  • Electrical and Instrumentation Inspections
