Product Details:
Payment & Shipping Terms:
|
| Name: | Magnesium Anode Rod Cleaning For Solar Water | Material: | Magnesium Anodes |
|---|---|---|---|
| Application: | Solar Water Heater | Dimensions: | Customized |
| Shape: | Mg Rod,bar, Cylinder, Square,D Shape,ribbon Etc. | Usage: | Corrosion Protection Thermocouple Retainers |
| Usage 2: | Protect The Gas Pipeline In-home Service Polarization High Resistance Electrolytes (soil And Water In The Steel Structure) | Anode Rod Manufacture: | Cast Magnesium Anode Rod |
| Mg Anode Rod: | Anode Rod For Water Heater | ||
| Highlight: | mg anode,magnesium sacrificial anode |
||
Standard : ASTM
Chemical Composition
| Shop sign | Alloy element | Impurity element ,less than | |||||||
| Al | Zn | Mn | Mg | Fe | Cu | Ni | Si | Ca | |
| AZ63 | 5.3-6.7 | 2.5-3.5 | 0.15-0.60 | Balance | 0.005 | 0.02 | 0.001 | 0.08 | — |
| High Potential | ≤ 0.05 |
≤ 0.03 | 1.20-2.0 | Balance | 0.005 | 0.02 | 0.001 | 0.08 | 0.04 |
| MGM1C | ≤0.01 | — | 0.50-1.3 | Balance | 0.01 | 0.01 | 0.001 | 0.05 | — |
| MG | ≤0.02 | ≤0.03 | ≤0.01 | ≥99.9% | 0.005 | 0.004 | 0.001 | 0.01 | — |
Electrochemical Property
| Shop sign | Open circuit potential |
Closed circuit potential
| Actual capacitance | Current efficiency |
| —V,Cu/CuSO4 | —V,Cu/CuSO4 | —(A·h/kg) | % | |
| MGAZ63B | 1.57-1.67 | 1.52-1.57 | ≥1210 | ≥55 |
|
High Potential | 1.57-1.67 | 1.47-1.57 | ≥1210 | ≥55 |
| MGM1C | 1.77-1.82 | 1.64-1.69 | ≥1100 | ≥50 |
Water Heater Anodes are available in several configurations, with welded or unwelded Hex-Head and Anode Outlet Devices (AODs). These anodes are typically used for the Cathodic Protection of Water Heaters, Tanks and Boilers. The linked-style water heater anodes are typically for replacement applications.
