Water Heater Anode: | Magnesium Anode For Water Heater | Anode Rod For Water Heater: | Az31/az63 Magnesium Anode Rod For Water Heater |
---|---|---|---|
Mg Anode Rod Application: | Protect Water Heater, Water Containers Of Steel Structure Magnesium Anode | Magnesium Anode Used In: | Soil And Water In The Steel Structure |
Soil And Water In The Steel Structure: | Protect The Gas Pipeline In-home Service Polarization High Resistance Electrolytes | Anode Rod Az31/az63: | Anode Rod For Water Heater Az63/az31 |
Highlight: | mg anode,magnesium sacrificial anode |
1. Magnesium anode for water heater (soil and water in the steel structure)
2. Standard:
ASTM B 843-1995
3. Application:
Water Heater,Water container,Pre-polarization of steel structure in seawater,Gas pipe,Anticorrosion of steel and iron structure where high resistant and electrolyte(soil and water) existed.
4. Chemical Composition
Type | Alloy Element | Impurity Elements(Max) | ||||||||
Al | Zn | Mn | Mg | Fe | Cu | Ni | Si | Other | ||
Each | Total | |||||||||
MGAZ63B | 5.3-6.7 | 2.5-3.5 | 0.15-0.60 | Balance | 0.003 | 0.01 | 0.001 | 0.08 | _ | 0.30 |
MGAZ31B | 2.7-3.5 | 0.6-1.4 | 0.2-1.0 | Balance | 0.003 | 0.01 | 0.001 | 0.08 | 0.05 | 0.30 |
5. Dimensions
Anode Dia(mm) | Core Dia(mm) | Screw | Unit weight(g/cm) |
φ13.97 | Φ2.0 | NPE-ASMT/BSP/G/R | 2.83 |
Φ19.05 | Φ3.4 | NPE-ASMT/BSP/G/R | 5.66 |
Φ21.34 | Φ3.4 | NPE-ASMT/BSP/G/R | 6.85 |
Φ26.67 | Φ3.4 | NPE-ASMT/BSP/G/R | 10.42 |
Φ33.40 | Φ3.4 | NPE-ASMT/BSP/G/R | 16.08 |
Φ39.65 | Φ4.8 | NPE-ASMT/BSP/G/R | 23.07 |
Φ51.40 | Φ4.8 | NPE-ASMT/BSP/G/R | 37.96 |
*Customized Size Available |
magnesium anode
(1)Corrosion protection magnesium anode
(2)protect water heater, water containers of steel structure magnesium anode
(3)protect the gas pipeline in-home service polarization high resistance electrolytes (soil and water in the steel structure)
