Application: | Linear Anode For Buried OIL / GAS Pipelines | Standard: | Splice Kits For AnodeFlex 1500 Linear Anode System |
---|---|---|---|
Shape: | Mmo-surfaced Anodes ,Polymeric Anodes For Improved Polymer Light-emitting | Content: | Copper Core Linear Anode For Cathodic Protection System |
Type: | Grid Anodes MMO | ||
Highlight: | sacrificial anode protection,magnesium sacrificial anode |
MMO Discrete Anodes Copper Core Linear Anode For Cathodic Protection System
MIXED METAL OXIDE ACTIVATED TITANIUM WIRE PIGGYBACK ANODES Activation: Noble Mixed Metal Oxides consisting of IrO2 and Ta2O5 Substrate Material: Titanium to ASTM Grade 1 or 2 Working Environment: Evolution of O2, Cl2 or a combination of both Nominal Design Life: Typically 20 years when operating at an anode current density of 100 A/m2 – coating loading can be adjusted for any combination of current output and design life. Dimensions of Piggyback Anode: Dimension of Ti Wire: 1.5 mm dia. or 3 mm dia. Current Output of Piggyback : 1.5 mm dia. Ti Wire – 0.5 A/m ; 3.0 mm dia. Ti Wire – 1A/m Lengths: From 1 m to 50 m* *Longer lengths are available on request Header Cable: Typically 10 mm2 or 16 mm2 XLPE/PVC connected to the MMO/Ti wire anode every 10 m, header cable or spacing between connections can be adjusted to suit the particular soil resistivity of operation Cable Tail: a cable tail, typically of 1 m to 5 m can be provided at one end or both ends of the Sock Anode to allow connection to the power feed from the TR
Applications 3mm Ø wire New Construction Tank Bottom CP Replacement Tank Bottom CP Applications 1.5mm Ø wire Parallel Anode Pipeline CP Underground Cable Ducts CP
Easy to Install ‐‐ Cost Effective o Arrives on site Ready to Lay in Place o Follows Structure Symmetry so achieves maximum cathodic protection efficiency by running a continuous anode parallel to the cathode. o 100% Factory Connections – high QC o Continuous Anode Technology o Optimized Current Distribution o Optimized Power Efficiency o Optimized Low Groundbed Resistance
