Application: | LMMO/Ti Linear Anode For Buried Pipelines | Standard: | Continuous MMO Ti Wire Coated Flexible Linear Anodes For Underground Pipeline Cathodic Protection |
---|---|---|---|
Shape: | Mixed Metal Oxide Titanium Flexible Anode | Content: | Impressed Current Cathodic Protection |
Type: | Impressed Current C Anode ICCP | ||
Highlight: | sacrificial zinc anodes,alloy sacrificial anode |
ICCP Polymer anode,MMO Anodes ( Mixed Metal Oxide) for Cathodic protection
Item | Parameters |
Model P/N | MMO/Ti Wire Anode 1.5mm Dia) ELTA-30(MMO/Ti Wire Anode 3mm Dia) |
Outer Dia. | 38-40mm |
MMO/Ti wire anode Dia. | 1.5mm,3mm |
Current output | =52mA/m, customizable |
Designed life | =40Y, customizable |
Cable | 1×10mm2/ Halar,HMWPE/PVC or HMWPE are optional. |
Carbon breeze content | =98.5% |
Carbon breeze resistivity | ~0.05O·cm,per G.L.C.-C-12A at 23ºC, 10 bar |
MMO wire and cable contact resistance | =0.0009O |
Anode weight | 1.3-1.5Kg/m |
Length per roll | 500m;1000m |
Bursting strength | 575 N per ISO 3303 |
Abrasion resistance | 219 cycles to failure per ASTM D-4157 |
Fluid resistance | Pass, 6-month immersion test |
Chlorine resistance | Pass, 6-month immersion test |
UV resistance | 55% tear strength loss per ASTM G-53, 8 hrs @ 60ºC (140ºF), 4 hrs condensation @ 50ºC (122ºF) |
Package: in roll
Material: ICCP polymer anodes are typically made using a conductive polymer material mixed with various additives. The conductive polymer is responsible for delivering the electrical current required for cathodic protection.
Function: The primary function of ICCP polymer anodes is to protect metallic structures from corrosion. When connected to a power source, the anodes release a controlled electrical current that counteracts the natural tendency of metals to corrode. This current helps to create a protective electrochemical environment around the structure, preventing the formation of corrosion-inducing reactions.
Installation: ICCP polymer anodes are available in various forms, including sheets, tapes, rods, and wires. They can be easily installed on the surface of the structure to be protected, typically by bonding or mechanical attachment methods.
Performance: These anodes have excellent electrical conductivity, ensuring efficient distribution of the cathodic protection current. They also have a long service life and can withstand harsh environmental conditions, such as high temperatures, moisture, and chemical exposure.
Advantages: ICCP polymer anodes offer several advantages over traditional sacrificial anodes (e.g., zinc or aluminum). They provide a more predictable and controllable current output, allowing for more precise and tailored protection. Additionally, they have a relatively low weight and volume, making them easier to handle and install. They are also environmentally friendly as they do not contain hazardous materials like some sacrificial anodes.
