Continuous Impressed Current Cathodic protection MMO/Ti Linear anodes

China Continuous  Impressed Current Cathodic protection MMO/Ti Linear anodes supplier

Large Image :  Continuous Impressed Current Cathodic protection MMO/Ti Linear anodes

Product Details:

Place of Origin: China
Brand Name: High Broad or OEM
Certification: ISO, DNV,BV
Model Number: ASTM B348 GRADE I/II

Payment & Shipping Terms:

Minimum Order Quantity: 1 meter
Price: negotiable
Packaging Details: on pallet
Delivery Time: 1FCL: 14 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
Supply Ability: 30000meters/month
Detailed Product Description
Application: LMMO/Ti Linear Anode For Buried Pipelines Standard: Continuous MMO Ti Wire Coated Flexible Linear Anodes For Underground Pipeline Cathodic Protection
Shape: Mixed Metal Oxide Titanium Flexible Anode Content: Copper Core MMO/Ti Linear Anode For Cathodic Protection System
Type: Impressed Current C Anode ICCP
Highlight:

sacrificial zinc anodes

,

aluminum zinc anode

Continuous Linear anodes,Impressed Current Cathodic protection MMO/Ti Linear anodes



Mixed Metal Oxide (MMO) and linear anode systems for storage tank soil side corrosion prevention, have long been established as the go-to anode system for corrosion prevention systems. However, the effectiveness of these anodes



  •
  •
Diameter of flexible anode 39+/-2 mm
Diameter of MMO/Ti anode wire >= 1.0 mm
Designed service life of anode >= 25 years
Consumption rate of MMO/Ti anode wire ( with backfill materials) <= 6 mg/A.a
Output current
  1.
Thickness of metallic oxide coating >= 6 g/m2
Resistivity of mixed metallic oxides(Ω/cm) 10 -5Ω˙cm
Contact Resistance at the joints between andoe and cable <= 1mΩ
Resistance of anode <= 0.007 Ω/m
Carbon content of backfill coke powder >= 98%
Resistivity of coke powder <= 0.55 Ω˙cm
Fabric cladding jacket of anode Resistant to acid/alkaline and chlorine; Permeable
External woven mesh Resistant to abrasion and ambient temperature variation
Weight of anode >= 1.3 kgs/meter
Length of each coil 700 meters or customized





Continuous  Impressed Current Cathodic protection MMO/Ti Linear anodes



Continuous  Impressed Current Cathodic protection MMO/Ti Linear anodes
