Custom Ingot CP ICCP Sacrificial Magnesium Aluminum Anode Alloy For Heater Treater Offshore Onshore Steel Construction

Good quality Aluminum Sacrificial Anode for sales
Good products, Nice services. I trust High Broad brand.

—— Sheikh Abdulla

I puchase cathodic protection anodes from High Broad from year 2006. We worked well as best partners.

—— Narrisa Kotsonis

I'm Online Chat Now

Custom Ingot CP ICCP Sacrificial Magnesium Aluminum Anode Alloy For Heater Treater Offshore Onshore Steel Construction

China Custom Ingot CP ICCP Sacrificial Magnesium Aluminum Anode Alloy For Heater Treater Offshore Onshore Steel Construction supplier
Custom Ingot CP ICCP Sacrificial Magnesium Aluminum Anode Alloy For Heater Treater Offshore Onshore Steel Construction supplier Custom Ingot CP ICCP Sacrificial Magnesium Aluminum Anode Alloy For Heater Treater Offshore Onshore Steel Construction supplier Custom Ingot CP ICCP Sacrificial Magnesium Aluminum Anode Alloy For Heater Treater Offshore Onshore Steel Construction supplier Custom Ingot CP ICCP Sacrificial Magnesium Aluminum Anode Alloy For Heater Treater Offshore Onshore Steel Construction supplier

Large Image :  Custom Ingot CP ICCP Sacrificial Magnesium Aluminum Anode Alloy For Heater Treater Offshore Onshore Steel Construction

Product Details:

Place of Origin: China
Brand Name: HB
Certification: ASTM G-97, ISO, DNV
Model Number: sacrificial anode

Payment & Shipping Terms:

Minimum Order Quantity: 10 Kilograms
Price: according to order quantity
Packaging Details: On pallet with steel bundles
Delivery Time: 1 FCL:14 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,PayPal
Supply Ability: 300 Metric Ton/Metric Tons per Month
Detailed Product Description
Content: Mg Mn Al Application: Anti Fouling Underearth Tanks
Shape: Rod Shape Sacrificial Magnesium: Underground Pipeline Anodes
Material: Alloying Mg Unit Weight: 9lb, 20 Lb, 48 Lb , 60 Lbs 100 Lbs
Highlight:

Sacrificial Magnesium Aluminum Anode Alloy

,

Ingot Cpc Aluminum Anode Alloy


Sacrificial Anode Magnesium Sacrificial Anode Custom Ingot Cpc Used Sacrificial Magnesium Aluminum Anode Alloy



Quick Details
Place of Origin:
Hunan, China
Brand Name:
HB metal
Model Number:
Customized
Application:
steel tanks anti fouling
Shape:
rod
Material:
Magnesium
Chemical Composition:
Mg,Mn,Al,Zn,Cu, Mg balance, Mg balance
Keywords:
magnesium anode
Surface:
smooth
color:
silver
Product technology:
Casting or extruded
Length:
1000 mm
Diameter:
30-220 mm
Certificate:
ISO9001
MOQ:
10pc


Custom Ingot CP ICCP Sacrificial Magnesium Aluminum Anode Alloy For Heater Treater Offshore Onshore Steel Construction

HB
Mag Anode Chemistry*
Aluminum
Manganese
Copper
Silicon
Iron
Nickel
Others each
Magnesium
0.01% max
0.50 - 1.3%
0.02% max
0.05% max
0.03% max
0.001% max
0.05% max
Remainder


Our advantages:

No hazardous sealant or primer is needed or used to seal the cable-to-anode connection, which is good for the environment. Worker safety is improved by eliminating the labor intensive molten liquid sealant. Superior protection of the cable from sharp bends as this connection method is much more tolerant of multiple bends. Copper cable does not become brittle due to overheating of the copper. More consistent connections



Custom Ingot CP ICCP Sacrificial Magnesium Aluminum Anode Alloy For Heater Treater Offshore Onshore Steel Construction

Chemical compositions of cast magnesium anodes (%)
ElementHigh potentialAZ63BAZ63CAZ63D
Al<0.015.30-6.705.30-6.705.0-7.0
Zn---2.50-3.502.50-3.502.0-4.0
Mn0.5-1.300.15-0.700.15-0.070.15-0.70
Si (max)0.050.100.300.30
Cu (max)0.020.020.050.10
Ni (max)0.0010.0020.0030.003
Fe (max)0.030.0050.0050.005
Others each0.05--------
Others total0.300.300.300.30
MgBalanceBalanceBalanceBalance



Electrochemical Properties of cast magnesium anodes
ItemOpen-circuit VoltageClose-circuit VoltageActual capacitanceCurrent efficiency
 (-V)(-V)(A.h/g)(%)
High Potential1.70-1.751.57-1.62≥ 1.100≥ 50

Low Potential

(AZ63)

1.50-1.551.45-1.50≥ 1.105≥ 50

Note: Open and Close-circuit voltage is relative to Saturated Calomel Electrode (SCE)
